3 LCD system

New LCD panel 0.76" (19 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10

6,912,000 (1920 x 1200 x 3) pixels

Powered

Powered

Approx. x 1.6

1.39:1 to 2.23:1

Powered

-5%, +70%

+/- 32%

Laser diode

40'' to 600'' (1.02 m to 15.24 m) (measured diagonally)

7300lm *3 / 8000lm (Center)*4

5840lm

-

7300lm

5840lm

-

20000 hours

30000 hours

?:1

15 kHz to 93 kHz

23 Hz to 63 Hz

Maximum signal resolution: 1920 x 1200 *6

NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p,3840/60p, 3840/30p, 3840/25p, 3840/24p,4096/60p, 4096/30p, 4096/25p, 4096/24p

+/- 30 degrees

+/- 30 degrees

RGB / Y PB PR input connector:Mini D-sub 15 pin (female)
Audio input connector: Stereo mini jack

DVI input connector: DVI-D 24-pin (single link), HDCP support
Audio input connector: Shared with INPUT A

HDMI input connector: HDMI 19-pin, HDCP support
Audio input connector: HDMI audio support

HDBaseT interface connector: RJ45, 4 play (Video, Audio, LAN, Control)

Video input connector: BNC
Audio input connector: Shared with input A

Monitor output for Input A Connector: Mini D-sub 15-pin (female)
Audio output connector: Stereo mini jack

Monitor output for Input B Connector: DVI-D 24-pin (single link), HDCP not supported
Audio output, Monitor out connector: Stereo mini jack

D-sub 9-pin (male) / RS232C

RJ45, 10BASE-T/100BASE-TX

Stereo mini jack, Plug in power DC5V

TYPE-A (for F/W update) , TYPE-A (for Power supply)

38 dB / 36 dB

0°C to 45°C (32°F to 109°F) / 20% to 80% (no condensation)

-10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation)

AC 100 V to 240 V, 5.1 A to 2.2 A, 50 Hz / 60 Hz

Mode: Standard: 506 W

Mode: Standard: 474 W

0.5W (when “Standby mode” is set to “Low”)

0.5W (when “Standby mode” is set to “Low”)

9.8 W (LAN)
10.6 W (HDBaseT)
10.6 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")

10.9 W (LAN)
11.6 W (HDBaseT)
11.6 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")

Approx. 10 Minutes

1617 BTU/h

1727 BTU/h

460 x 169 x 494 mm
18 1/8 x 6 3/4 x 19 1/2 inches

Approx. 13 kg (29 lb)

VPLL-3003 / 3007 / Z3009 / Z3010 / Z3024 / Z3032

With supplied standard lens

The figures are approximate. They vary depending on the environment or how the projector is used.

The value is in accordance with ISO 21118, and may differ depending on the actual unit. Brightness and contrast vary depending on use conditions and environments.

The value is light output measured at centre area of screen in Standard mode, and average of all products shipped.

Estimated time until light output declines to 50 % varies depending on environment.

Available for VESA Reduced Blanking signal.
