Club3D Dokovací stanice USB 3.0 + mini DP, MST (2xminiDP/3x USB 3.1/Ethernet)

Typ príslušenstva:Dokovacie stanice a replikátory.... viac
Bežná cena: 166.9  (-11%)
123.5 € bez DPH
Skladom
148.2 €
ks
Kód: 795088
Kód dod.: CSV-3103D
EAN: 8717249401070
Záruka: 24 Měsíc(ů)
Výrobca: Club 3D
Popis a parametre

Club3D Dokovací stanice USB 3.0 + mini DP, MST (2xminiDP/3x USB 3.1/Ethernet)

USB 3.0 + Mini DisplayPort™ MST Docking Station
CSV-3203 The SenseVision USB 3.1 Gen1 + Mini DP Docking Station can easily connect to your Microsoft Surface Pro 2/3/4 Tablet or Laptop and enable connectivity to a full range of peripherals like keyboards, mice and storage devices. It has three built-in USB 3.1 Gen1 ports, two MiniDisplayPort™ 1.2 outputs and one Gigabit Ethernet port. You can even extend the connections of the USB ports further to add more peripherals or USB devices. Featuring Multi Stream Transport technology, it supports dual screen setup with resolutions up to 2 x 2560x1600p 60Hz. ?Dual Mode DisplayPort™ (DP++)
The MST Hub supports Dual Mode DisplayPort™ (DP++) which allows the use of DVI or HDMI™ Monitors via passive Adapters.


Flexibility
Ultrabooks, Tablets and other slim notebook computers are sleek but they often lack connectivity possibilities. With SenseVision USB 3.1 Gen1 + Dual Mini DP docking station you have access to all your devices through just a single USB 3.0 and Mini DisplayPort™ cable.


Add on
Get even more from your Surface Pro 2/ 3/4 tablet with its powerful Mini DisplayPort™ output. Microsoft Surface Pro tablets have powerful Intel Core CPU’s and are capable to drive up to 2 external displays using Multi Stream Transport.


Scan button
The SenseVision USB 3.1 Gen1 + Dual Mini DP docking station features a scan button which can/should be used when the PC does not recognize the connected screens.




TECHNICAL SPECIFICATIONS



























Product Name USB 3.1 Gen1 + Mini DisplayPort MST Docking Station
Product Series SenseVision
Item Code CSV-3203
EAN 8717249401025
UPC Code 854365005855
Inteface USB 3.1 Gen1 & Mini DisplayPort 1.2
Voltage DC 19.5V
Output 2x Mini Displayport 1.2
3x USB 3.1 Gen1 Type A
1x Gigabit Ehternet RJ45
Features • Compliant with DisplayPort™ 1.2 secifications
• Supports main link rates of 5.4Gbps (HBR2), 2.7Gbps (HBR) and 1.62Gbps (RBR)
from source
• Supports DP 1.2 Multi-Stream Transport (MST)
• Supported Max Resolutions:
For Single Screen Setup: 3840x2160 @ 60Hz
For Dual Screen Setup: 2 x 2560x1600 @ 60Hz
• Expands a USB 3.1 Gen1 port to three USB 3.1 Gen1 ports
• Gigabit Ethernet 10/100/1000 port
• Ethernet supports Wake-on-LAN technology, crossover detection
• Power Adapter: 100-240VAC, 50/60Hz, operating 19.5W
Package Contents Club 3D SenseVision USB 3.1 Gen1 + Mini DisplayPort MST Docking Station
CD driver
Power Adapter
Supported Operating Systems Windows 10, 8.1

.
Typ príslušenstva
Dokovacie stanice a replikátory
Špecifikácia kábla / redukcie
Adaptér, Redukce
